Description

Trough Length: 24′ (732 cm)
Engine: Vanguard® 5 hp (169 cc)
Trough Width: 8″ (20 cm) wide flared out to 20″ (51 cm) at bottom
Trough Depth: 7″ (18 cm)
Maximum Pile Height: 13.5′ (411 cm)
Power Source: Vanguard 5HP (160 cc)
Chain Type: 662 Pintle Heavy Conveyor Chain
Chain Drive: Engine Direct-Drive, Bottom Sprocket
Cleat: 2″ (5 cm) High Serrated
Tires: 5.30-12
Hitch: Clevis
Total Weight: 1040 lbs (472 kg)
Dimensions Raised (LxWxH): 260″ x 74″ x 174″ (660 cm x 188 cm x 442 cm)
Dimensions Lowered (LxWxH): 307″ x 74″ x 83″ (780 cm x 188 cm x 211 cm)
